WX-620 Dual GPU WS KALAMIT
Intel i9 14900k
Asus Pro-Art Z790 10G
up to 192GB RAM
up to 2x Nvidia RTX 4090
up to 16TB NVMe SSDs
Seasonic Prime PX Series
Corsair 7000D
Alphacool & Noctua Cooling
Silent Dual GPU Workstation
for
Redshift, V-Ray, Lumion and OctaneRender
Silence & Performance Optimized
Unmatched performance and silence at sub 29dB under full load and 23dB in idle.*
To achieve the best cooling possible we combine Hardware Labs’ Nemesis Radiators and Alphacool Core and ES Blocks with the quietest fans from Noctua to enable the GPUs performance while staying at cool temperatures and being near silent, especially when compared to similar air cooled workstations or rack mount solutions.
Ideal for creating a more quiet and concentration friendly environment for the user and potentially the people around you, albeit in a small office or in your creative hub at home.
Dual D5 Pumps for Fail-Safe Redundancy
Two EK D5 PWM pumps, connected in serial help overcome the many restrictive water cooling parts by keeping the flow rate high,
and providing a needed redundancy for the workstation, in case of a pump failure.
Built for the best Motion Design and 3D Rendering experience
RTX 4090s are the first graphics cards that have it’s rendering performance truly measured in Frames per Second, instead of Seconds per Frame.
Double that - and you allow the user to view scenes in near-real-time, while changing angles and parameters in unprecedented speeds.
Ideal for creative artists using Cinema4D’s plugin Redshift, or similar GPU accelerated rendering environments like V-Ray, Blender’s Cycles, Ingido- or OctaneRender.
Customize YOUR Build!
We manufacture all our PCs with your custom input on your desired color accents and material finishes!
Available options for finishes include:
Nickel
Black Nickel
Satin Titanium
Matte-Black
Color Accents can be chosen freely.
You can submit these per E-Mail or via the “Contact” tab, after ordering or when requesting your quote.
Hand-built in Hamburg
Base Specs / Spec Options:
CPU:
Intel i9 14900k 8c/32t so.1700
GPU
1-2x Nvidia RTX 4090 Zotac 24GB GDDR6X*
RAM
64GB G.Skill TridentZ5 6000MT/s CL36 DDR5
96GB G.Skill TridentZ5 6400MT/s CL32 DDR5
128GB Corsair Vengeance 5400MT/s CL40 XMP OC DDR5
192GB Corsair Vengeance 5200MT/s CL40 XMP OC DDR5
MB
Asus ProArt Z790E-Creator WIFI6E, 10Gbit and 2.5Gbit LAN
PSU
Seasonic Prime PX1000 80+ Platinum (single GPU config.)
Seasonic Prime PX1600 80+ Platinum (dual GPU config.)
SSD 1-2
2TB Samsung 980 Pro PCIe4.0 Read: 7000MB/s | Write: 5100MB/s | TBW: 1.3PB
2TB Samsung 980 Pro PCIe4.0 Read: 7000MB/s | Write: 5100MB/s | TBW: 1.3PB
SSD Options
Up to 16TB NVMe with
4x 4TB Seagate Firecuda PCe4.0 Read: 7300MB/s | Write: 6900MB/s | TBW: 5.1PB
or
Up to 32TB SATA:
4x 8TB Samsung QVO
Cooling
Fans
11x Noctua NF-A12 Chromax
CPU
Alphacool Core1 Block so.1700
GPU
Alphacool ES 4090 Single Slot Block(s)
Fittings
EK Quantum Torque 16mm Fittings
Pump
EK Dual D5 XTOP PWM, dual D5 pumps
Radiators
Hardware Labs 2x 480mm 1x 360mm
Sensors
Water Temp. Sensor
Tubing
Alphacool 16/10mm Soft EDPT Tubing
*Acoustic testing with side panel on, 45cm distance to the case with custom tuned fan profile under load at ~850rpm +-5%, Load: Furmark and CinebenchR23 looped, testing done with 2x RTX 3080ti Version of this Workstation.
**Exact manufacturer of GPU can vary due to availability, because of this, blocks and tubing runs can be different than displayed on the pictures, but are still representative of the build delivered.
